| Machine model | K-9060 | K-1390 | K-1610 |
| Engraving area | 900 x 600mm | 1300 x 900mm | 1600 x 1000mm |
| Laser power | 60/80/100/120W | 100/120/150/200/260W | 100/120/150/200/260W |
| Engraving speed | 0-64000 mm/min | ||
| Resolution | 0.025mm | ||
| Minimum shaping character | Chinese Character: 2mm ,Letter: 1mm | ||
| Resetting Positioning accuracy | ±0.1mm | ||
| Transmission | Linear guide | ||
| Operating humidity | 0-45°C,5%-95%(free of condensed water) | ||
| Graphic format supported | BMP.GIF.JPG. PCX.TGA.TIFF.PLT.CDR.DWG.DXF | ||
| Power supply | AC220V ± 1 0%.50Hz/60Hz | ||
| Cooling method | Water | ||
| Gross power | <2000W | ||
| Net weight | 420KG | 450KG | 480KG |
| Dimension | 1400x1200x1100mm | 1900 x 1530 x 1100mm | 2160x1600x1100mm |
